    CNC Horizontal And Vertical PVC Pipe Making Machine , Auto Pipe Cutting Machine

    Ask Lasest Price
    Brand Name : D&T
    Model Number : DTC-FKD2012
    Certification : CE
    Price : USD 10000 - 50000 / set
    Payment Terms : L/C, T/T, Western Union,paypal
    Supply Ability : 20 sets / month
    Delivery Time : 40 working days
    • Product Details
    • Company Profile

    CNC Horizontal And Vertical PVC Pipe Making Machine , Auto Pipe Cutting Machine

    D&T CNC Horizontal and Vertical PVC Pipe Making Machine Auto Pipe Cutting Machine


    suit for: flexible and rigid PU, EPS, PE, PVC, EVA, Rock wool and phenol foams.
    Fast Wire Contour Cutter
    Cutting line: Fast cutting wire
    The D&T Fast wire Contour Cutter is a versatile machine, which uses an abrasive wire moving at high-speed to enable it to cut complex 2D
    shapes from a wide range of rigid and flexible foams. These include flexible and rigid PU, EPS, PE, PVC, EVA, Rock wool and phenol foams.
    All the machines are driven by the remarkable D&T Profiler software, which speeds up the design process and enables the operator to obtain
    the best yield from the foam block.
    Fast Wire Contour Cutter has perfect safe system to provide the accident. It include: All Motor will stop when the safety door be opened;
    Exigency button on both machine and control box for accident; brake system when cutting line broken.









    Technical Specifications

    Max.Block size2500*1300*1000mm (L*W*H)
    Control DeviceIndustrial computer
    Computer Operation SystemWin7
    SoftwareD&T Profiler
    Acceptable File FormatsDXF/DWG/CDR
    Number of Cutting WireDual Wire (Horizontal+Vertical)
    Cutting Wire Length of Horizontal~8260mm(should be confirmed by maker by machine)
    Cutting Wire Length of Vertical~9050mm(should be confirmed by maker by machine)
    Cutting Wire DiameterΦ0.8~2.0mm
    Flying Wheel Diameter400mm
    Mainly MotorABB,3kW*2pcs
    Running Speed of the Wheel2860rpm
    InverterPanasonic,for 3kW motor
    Cutting Speed0~10m/min
    Precision±0.5mm
    Total Power14kW,380/220V,50Hz (customizable)
    Gross Weight2800kg
    Overall Dimension6240*5460*2690mm
